Mitutoyo 500-764-20 Coolant Proof Caliper

Mitutoyo 500-764-20 Coolant Proof Caliper

product overview

The carbide-tipped jaws of the Mitutoyo 500-764-20 coolant proof caliper enable for accurate measurements in a variety of settings.
Another benefit of this product is its outstanding resistance to water and dust (protection level IP67), which allows it to be utilized in machining scenarios where cooling liquid can be sprayed.
With a precision of ±0.03mm / ±0.0015″, this device offers a measuring range of 0-300mm / 0-12″ and may be used for both metric and inch measurements.

Function

1 Before taking a measurement, take careful to “zero” or reset the LCD reading.

2 Start rotating the thumb once “0” appears on the display until the item is securely held in place by either the inner or outer jaws.

3 Use the outside (lower) and inner (upper) jaws to read the object’s outer and inner diameters, respectively.

Mitutoyo 500-764-20 coolant proof caliper Features

• enabling use in situations where coolant fluid may splash during machining.
• extremely strong water resistance.
• unusually extended battery life.
• plastic box that resists dust and moisture.
• readability of measuring speed.
• delicate and exact.
• Measurements up to 0-300mm / 0-12″ are possible.
• obtainable in metric and inch.
• Accuracy: ±0.03mm / ±0.0015″.
• dust resistance.
• enduring jaws.

Mitutoyo 500-764-20 Coolant Proof Caliper Specifications

• Depth bar:flat
• Thumb roller:Yes
• Data output:Yes
• Max. Permissible Error E MPE:±0,0015″
• Max. Permissible Error S MPE:±0,0025″
• Digital step:0,0005″/0,01 mm
• Max. response speed:Unlimited
• Display:LCD, character height 9 mm (150, 200 mm) 11 mm (300 mm)
• Delivered:In a case, including 1 SR-44 battery
• ORIGIN (ABS-Zero):Yes
• Auto Power OFF after 20 min. non use:Yes
• Low voltage alarm:Yes
• Battery life:Approx. 5 years under normal use
• Mass:345 g
