Rigol DSA815TG Generator Spectrum Analyzer

Rigol DSA815TG 1.5GHz Tracking Generator Spectrum Analyzer

The Rigol DSA815TG generator spectrum analyzer has a frequency range of 9 kHz to 1.5 GHz and a minimum resolution bandwidth of 10 Hz. The Rigol DSA800 series spectrum analyzers are small, lightweight, easy to use, and offer excellent value for money. The quality, performance, and features of these instruments, include a high-resolution color LCD display and various interfaces for remote communication.

 make these spectrum analyzers very versatile and ideal for various environments such as research and development laboratories, educational institutions, and Those interested in home electronics production and laboratories. To buy DSA815TG Generator Spectrum Analyzer at an unbelievable price and quality, visit our experts.

Rigol DSA815TG Generator FEATURES

• Frequency range from 9 kHz to 1.5 GHz, Integrated tracking generator
• Average displayed noise level (DANL) <-155 dBm/Hz typ. with activated preamp
• Minimum resolution bandwidth (RBW) 10 Hz
• Phase noise <-80 dBc/Hz at 10 kHz Offset
• Level measurement uncertainty <1.5 dB nom.
• AM/FM demodulation function
• 8-inch high-resolution screen (800 x 480)
• The linear and logarithmic frequency axis, Connectivity: LAN (LXI), USB host & The
• PictBridge supports the compact size and light weight of the

DSA815TG Spectrum Analyzer SPECIFICATIONS

• Display 8″ LCD, 800*480 pixels, Resolution 1 Hz
• Internal reference frequency 10 MHz
• Third-order intercept (IP3):  +10 dBm (-815), +7 dBm (-832E), +11 dBm (-832), +15 dBm (-875)
• Maximum input voltage 50V DC, Maximum input power 30 dBm
• Amplitude display
• Log: 1 dB – 200 dB
• Linear: 0 – Reference level
• Connections USB 2.0 type A, USB 2.0 type B, Lan
• Frequency counter: Yes
• Weight (without box) 4.25 – 4.55 Kg, Dimensions 361.6 x 178.8 x 128 mm (WxHxD)
